LM2904AQTH-13 / SMD/SMT/ Diodes Incorporated / TSSOP-8
The LM2902Q/LM2902AQ/LM2904Q/LM2904AQ series consist of two or four independent high-gain operational amplifiers with very low input offset voltage specification. They are designed to operate from a single power supply over a wide range of voltages; however, operation from split power supplies is also possible. They offer low power supply current independent of the magnitude of the power supply voltage.
The LM2904_Q dual devices are available in SO-8, TSSOP-8 and MSOP-8; and the LM2902_Q quad devices are available in SO-14 and TSSOP-14. All of them are in industry-standard pin outs, and use “green” mold compound as standard.
The LM2902Q/LM2902AQ/LM2904Q/LM2904AQ are characterized for operation from -40°C to +125°C, qualified to AEC-Q100 Grade 1 and are Automotive Compliant, supporting PPAPs.
| Product Attribute | Attribute Value |
|---|---|
| Diodes Incorporated | |
| Product Category: | Operational Amplifiers - Op Amps |
| RoHS: | Details |
| SMD/SMT | |
| TSSOP-8 | |
| 2 Channel | |
| 36 V, +/- 18 V | |
| 700 kHz | |
| 40 mA | |
| 300 mV/us | |
| 2 mV | |
| 3 V, +/- 1.5 V | |
| - 40 C | |
| + 125 C | |
| 20 nA | |
| 700 uA | |
| No Shutdown | |
| 70 dB | |
| 40 nV/sqrt Hz | |
| AEC-Q100 | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| 3 dB Bandwidth: | - |
| Amplifier Type: | General Purpose Amplifier |
| Brand: | Diodes Incorporated |
| Gain V/V: | 100 V/mV |
| Ios - Input Offset Current: | 2 nA |
| Maximum Dual Supply Voltage: | +/- 18 V |
| Minimum Dual Supply Voltage: | +/- 1.5 V |
| Output Type: | - |
| Product: | Operational Amplifiers |
| Product Type: | Op Amps - Operational Amplifiers |
| PSRR - Power Supply Rejection Ratio: | 100 dB |
| Factory Pack Quantity: | 2500 |
| Subcategory: | Amplifier ICs |
| Topology: | Dual |
| Vcm - Common Mode Voltage: | 0 V to 34.5 V |
| Unit Weight: | 0.178433 oz |
