XIO2001IPNP / PCI Interface IC x1 PCI Exp to PCI Bus Trans Bridge
| Product Attribute | Attribute Value |
|---|---|
| Texas Instruments | |
| Product Category: | PCI Interface IC |
| RoHS: | Details |
| Bridge - PCIe to PCI | |
| 125 MHz | |
| 1 Lane | |
| 1 Port | |
| 3.3 V, 5 V | |
| 3.3 V, 5 V | |
| - 40 C | |
| + 85 C | |
| SMD/SMT | |
| HTQFP-128 | |
| Tray | |
| Brand: | Texas Instruments |
| Data Bus Width: | 32 bit |
| Data Rate: | 2 Gb/s |
| Development Kit: | XIO2001EVM |
| Moisture Sensitive: | Yes |
| Operating Supply Voltage: | 3.3 V, 1.5 V |
| Product Type: | PCI Interface IC |
| Propagation Delay Time: | 11 ns |
| Series: | XIO2001 |
|
Factory Pack Quantity: |
90 |
| Subcategory: | Interface ICs |
| Unit Weight: | 0.017524 oz |
DESCRIPTION
The XIO2001 is a single-function PCI Express to PCI translation bridge that is fully compliant to the PCI Express to PCI/PCI-X Bridge Specification, Revision 1.0. For downstream traffic, the bridge simultaneously supports up to eight posted and four non-posted transactions. For upstream traffic, up to six posted and four non-posted transactions are simultaneously supported.
The PCI Express interface is fully compliant to the PCI Express Base Specification, Revision 2.0.
The PCI Express interface supports a ×1 link operating at full 250 MB/s packet throughput in each direction simultaneously. Also, the bridge supports the advanced error reporting including extended CRC (ECRC) as defined in the PCI Express Base Specification. Supplemental firmware or software is required to fully use both of these features
