TLK106LRHBT / Ethernet ICs Ind Temp SGL Port 10/100Mbs
The TLK10xL is a single-port Ethernet PHY for 10Base-T and 100Base TX signaling, integrating all the physical-layer functions needed to transmit and receive data on standard twisted-pair cables.
The device supports the standard Media Independent Interface (MII) and Reduced Media Independent Interface (RMII) for direct connection to a Media Access Controller (MAC). The device is designed for power-supply flexibility, and can operate with a single 3.3-V power supply or with combinations of 3.3-V and 1.55-V power supplies for reduced power operation.
The TLK10xL uses mixed-signal processing to perform equalization, data recovery, and error correction to achieve robust operation over CAT 5 twisted-pair wiring. The TLK10xL not only meets the requirements of IEEE 802.3, but maintains high margins in terms of cross-talk and alien noise
| Product Attribute | Attribute Value |
|---|---|
| Texas Instruments | |
| Product Category: | Ethernet ICs |
| RoHS: | Details |
| SMD/SMT | |
| VQFN-32 | |
| Ethernet Transceivers | |
| 10/100BASE-T, 100BASE-TX | |
| 1 Transceiver | |
| 10 Mb/s, 100 Mb/s | |
| MII, RMII | |
| 3.3 V | |
| - 40 C | |
| + 105 C | |
| TLK106L | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| Brand: | Texas Instruments |
| Moisture Sensitive: | Yes |
| Product Type: | Ethernet ICs |
| Factory Pack Quantity: | 250 |
| Subcategory: | Communication & Networking ICs |
| Unit Weight: | 0.002547 oz |
