ISO1176TDW / Digital Isolators Iso ProfiBus Xcvr
The ISO1176T is an isolated differential line transceiver with integrated oscillator outputs that provide the primary voltage for an isolation transformer. The device is ideal for long transmission lines because the ground loop is broken to allow the device to operate with a much larger common-mode voltage range.
The symmetrical isolation barrier of each device is tested to provide 4242VPK of isolation per VDE for 60 seconds between the line transceiver and the logiclevel interface.
| Product Attribute | Attribute Value |
|---|---|
| Texas Instruments | |
| Product Category: | Digital Isolators |
| RoHS: | Details |
| ISO1176T | |
| SMD/SMT | |
| SOIC-16 | |
| 1 Channel | |
| Unidirectional | |
| 40 Mb/s | |
| 2500 Vrms | |
| Capacitive Coupling | |
| 5.5 V | |
| 3 V | |
| 13.5 mA | |
| 80 ns | |
| - 40 C | |
| + 85 C | |
| Tube | |
| Brand: | Texas Instruments |
| Development Kit: | ISO1176TEVM |
| Duplex: | Half Duplex |
| Moisture Sensitive: | Yes |
| Operating Supply Voltage: | 3 V to 5.5 V |
| Pd - Power Dissipation: | 719 mW |
| Product Type: | Digital Isolators |
| Protocol Supported: | RS-485 |
|
Factory Pack Quantity: |
40 |
| Subcategory: | Interface ICs |
| Type: | RS-485 Isolated Transceiver |
| Unit Weight: | 0.019312 oz |
