MBRM140T1G / Screw Mount / onsemi / PowerMITE / Single
The Schottky POWERMITE employs the Schottky Barrier principle with a barrier metal and epitaxial construction that produces optimal forward voltage drop−reverse current tradeoff. The advanced packaging techniques provide for a highly efficient micro miniature, space saving surface mount Rectifier. With its unique heatsink design, the POWERMITE has the same thermal performance as the SMA while being 50% smaller in footprint area, and delivering one of the lowest height profiles, 1.1 mm in the industry. Because of its small size, it is ideal for use in portable and battery powered products such as cellular and cordless phones, chargers, notebook computers, printers, PDAs and PCMCIA cards. Typical applications are AC−DC and DC −DC converters, reverse battery protection, and “ORing” of multiple supply voltages and any other application where performance and size are critical.
| Product Attribute | Attribute Value |
|---|---|
| onsemi | |
| Product Category: | Schottky Diodes & Rectifiers |
| RoHS: | Details |
| Schottky Diodes | |
| Screw Mount | |
| PowerMITE | |
| Single | |
| Si | |
| 1 A | |
| 40 V | |
| 850 mV | |
| 50 A | |
| 500 uA | |
| - 55 C | |
| + 125 C | |
| MBRM140 | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| Brand: | onsemi |
| Height: | 1.15 mm |
| Length: | 2.18 mm |
| Product Type: | Schottky Diodes & Rectifiers |
| Factory Pack Quantity: | 3000 |
| Subcategory: | Diodes & Rectifiers |
| Termination Style: | SMD/SMT |
| Type: | Schottky Diode |
| Width: | 2.05 mm |
| Part # Aliases: | MBRM140T3G |
| Unit Weight: | 0.000575 oz |
