TPS7A4101DGNR / LDO Voltage Regulators 50Vin,50mA,Sgl Out LDO Linear Reg
| Product Attribute | Attribute Value |
|---|---|
| Texas Instruments | |
| Product Category: | LDO Voltage Regulators |
| RoHS: | Details |
| SMD/SMT | |
| MSOP-PowerPad-8 | |
| 1.175 V to 48 V | |
| 50 mA | |
| 1 Output | |
| Positive | |
| 25 uA | |
| 7 V | |
| 50 V | |
| 65 dB | |
| Adjustable | |
| - 40 C | |
| + 125 C | |
| 290 mV | |
| TPS7A4101 | |
| Reel | |
| Cut Tape | |
| MouseReel | |
| Brand: | Texas Instruments |
| Dropout Voltage - Max: | 290 mV |
| Maximum Output Voltage: | 48 V |
| Operating Supply Current: | 20 uA |
| Operating Temperature Range: | - 4 |
| Pd - Power Dissipation: | 1.83 W |
| Product Type: | LDO Voltage Regulators |
| Reference Voltage: | 1.173 V |
|
Factory Pack Quantity: |
2500 |
| Subcategory: | PMIC - Power Management ICs |
| Unit Weight: | 0.007055 oz |
FEATURES
• Wide Input Voltage Range: 7 V to 50 V
• Accuracy: – Nominal: 1% – Over Line, Load, and Temperature: 2.5%
• Low Quiescent Current: 25 µA
• Quiescent Current at Shutdown: 4.1 µA
• Maximum Output Current: 50 mA
• CMOS Logic-Level-Compatible Enable Pin
• Adjustable Output Voltage: about 1.175 V to 48 V
• Stable with Ceramic Capacitors:
– Input Capacitance: ≥ 1 µF
– Output Capacitance: ≥ 4.7 µF
• Dropout Voltage: 290 mV
• Built-In Current Limit and Thermal Shutdown Protection
• Package: High Thermal Performance HVSSOP-8 PowerPAD™
• Operating Temperature Range: –40°C to 125°C
